Name: 18650 37V 3000mAh Li Ion Battery Cells For Toys Consumer Electronics
Brand: Mottcell
Price: 2.40 USD

Brand Name : Mottcell

Model Number : 18650-2600

Place of Origin : Guangdong, China

Packaging Details : 200 units per box

Supply Ability : 5000000 Pack/Packs per Month

MOQ : 50 units

Price : $2.40/units 50-499 units

Weight : 45g, 45g

The charging ratio : 0.5C

The discharge rate : 0.5C

Anode Material : LFP

Application : Toys, Consumer Electronics, BOATS, Solar

Type : Li-Ion

red : red

Contact Now

18650 3.7V 3000mAh Li-Ion Battery Cells

No.	Item	General Parameter	Remark
1	Rated Capacity	Type 3000mAh	Standard charge and Standard discharge
1	Rated Capacity	(Min.) 2950mAh	Standard charge and Standard discharge
2	Nominal Voltage	3.7V
3	End of Charge Voltage	4.2V
4	Charge mode	CC,CV
5	Charging current	≤1A
6	Charging cut-off current	0.02C
7	Charging time	≈4h
8	Over-Charge Voltage Protection(cell)	4.35V±0.025VV
9	Over-Charge Voltage Protection(Pack)	4.35V±0.025VV
10	Discharging Current	1A
11	Maximum Continuous Discharging Current	3A

Continuous the table 1

No.	Item	General Parameter	Remark
12	Discharge of Peak current	________________
13	Over-disCharge Voltage(cell)	2.40V±0.08V
14	Over-disCharge Voltage Protection(Pack0	2.40V±0.08V
15	Over-Current Discharge Protection	6~9A
16	Short circuit protection	Have
17	Short circuit protection Release	_________________
18	Cell Dimension(		Can change
		Dia 18mm
		Height 65mm
19	Weight	≈65.0g
20	Operation Temperature Range	Charge 0~45°C	60±25%R.H. Bare Cell
20	Operation Temperature Range	Discharge -10~60°C	60±25%R.H. Bare Cell
21	Storage Temperature Range	1 month-20°C ~ 45°C	60±25%R.H. at the shipment state
		3 month(-20°C ~ 45°C
		1 year-20°C ~ 20°C
